ERW Steel Pipe

Usage

Used for low pressure liquid transportation, such as water, gas, and oil.

Oil drilling and machinery manufacturing, etc.

HFI

High Frequency Induction weld pipe

EFW

Electric Fusion Welded Pipe

Standard

API 5L, API 5CT, ASTM 53, EN10217, DIN 2458. IS 3589, JIS G3452, BS1387

Certificate

API 5L PSL1/ PSL2, API 5CT

Out Diameter

21.3mm -- 660.4mm(1/2"--26")

Wall Thickness

1.5 - 22.2mm

Length

0.3 – 18 M

Steel Grade

API 5L : GR B, X42, X46, X56, X60, X65, X70

API 5CT : K55, J55, N80 P110

ASTM A53: GR A, GR B

EN: S275, S275JR, S355JRH, S355J2H

GB : Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555

Surface

Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating,

Black Oil coating as per customer’s requirement

Test

Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength,

Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test,

Impact Test), Exterior Size Inspection, Hydrostatic Test.

Mill Test Certificate

EN10204/3.1B
